Based on the original car, the layout structure is the same as the original car; It presents the connection and control relationship between core components such as power battery management system, pure electric vehicle drive transmission system, EPS system, electric vehicle air conditioning and heating system, body electrical appliances, etc., and cultivates students' ability to analyze and deal with the fault of pure electric vehicles, which is suitable for the teaching and maintenance training of new energy vehicles in vocational colleges.

· The original pure electric vehicle system, each system is installed on a movable platform built of aluminum alloy profiles, and runs in linkage.
· The electrical connection method is the same as that of the real car, and the layout is reasonable.
· The parallel detection terminal is added to facilitate teaching measurement.
· Acrylic material is installed to make it easy to understand the internal structure and internal control elements.
· Supporting testing panel and electrical schematic.
· Equipped with intelligent fault setting and assessment system.
